Armoured S padlock

The padlocks from the Armoured Series with dimple keys

The IFAM’s Armoured Series padlocks have been reinforced with the Armoured S padlocks, with dimple keys. This type of key provides extra security to these robust padlocks. The Armored S have a brass body reinforced by a hardened steel casing and a steel shackle more than 10mm thick.

Download file technical sheet. armoured s padlocks pdf 724.35 kB

Features

Security level:	– Standard EN12320 Grade 4.
Body:	– Made of brass covered by a hardened and chrome plated casing.
Shackle:	– Made of hardened, chromed plated steel.
Opening / locking:	– Brass cylinder with drill resistant protection.
Keys:	– Security dimple keys. – Supplied with 2 keys. – Key compatible with: cylinders M+ (Anti Snap) Series and M Series cylinders; Titan and Huno 80 padlocks and CS88 M50/M70, CS88 LV and B6/50 rim locks.
Packaging:	– Box packed. – Blister packed.

Dimensions

	Armoured80	Armoured90
Body base (A)	82	91,7
Body height (B)	69	75
Shackle height (H)	14	18
Shackle diameter (D)	11	12
Shackle span (L)	30	35,7
Body thickness (C)	29	29,2
